Detail ECG ( EKG) 6/ 12 Channel Fukuda Denshi Cardimax FX 7542
SPECIFICATIONS
ECG Measurement items
Standard 12 leads : Rest 12 leads
Memory: any from 8-24s
Arrhythmia measurement : Any 3 leads with analysis
Memory: 40s, any from 1-3min., 100 or 200 beats ( max. 3min)
Autonomica nerve measurement : R-R measurement, Any lead
Memory: Any from 1-10min., 100 or 200 beats ( max. 10min)
Function
ECG leads : Standard 12 lead
Sampling Rate : 8000 sample/ s per channel
Defibrillator protection : Yes
Frequency response : 0.05 to 150Hz ( within -3dB)
Time Constant : 3.2s or greater
A/ D conversion : 18 bits
Common Mode Rejection Ratio : 103dB or greater
Filters : AC: 50 or 60 Hz, -20dB or less
Muscle: 25 or 35 Hz, -3dB ( -6dB/ oct)
Drift: 0.25 or 0.5Hz, -3dB ( -6dB/ oct)
Display : 12.1 inch Backlit XGA LCD with Touch Screen
Resolution : 1024 x 768 dots
Sensitivity : 1/ 4, 1/ 2, 1, 2, Auto
Recorder : Thermal dot array
Chart speed : 5, 10, 12.5, 25, 50 mm/ s
Data filing : PC Card slot X 1
CF Card slot X 1
Serial Port : RS232C X 3
DC input : 10mm/ 0.5V, 100KQ or greater ( 3ch)
Monitor output : 0.5V/ mV, 100Q or smaller
LAN port : IEEE802.3 10BASE-T
General
Regulatory standard : IEC60601-2-25
Conformity : CE marking for the 93/ 42/ EEC Directive
Power requirements : 100 to 240V AC Universal, 50/ 60Hz, or 9.6V DC ( option)
Power consumption : AC: 95VA, DC: 80W ( DC operation approximately 40min )
Dimension : ( W) 335 X ( D) 346 X ( H) 119 mm
Weight : Approximately 8kg
